Display

  • Type – Thin-film Transistor (TFT) Active Matrix Liquid Crystal
  • Size – 19.0″ diagonal
  • Image Size (W x H) – 374.8 mm x 299.8 mm
  • Native Resolution – SXGA (1280 x 1024, 5:4 aspect ratio)
  • Plug and Play – DDC1/2B compatible
  • Minimum Resolution – VGA (640 x 480)
  • Pixel Pitch – 0.293 mm x 0.293 mm
  • Number of Colours – 16.7 million
  • Brightness (white) – 250 nits (cd/m2) max
  • Viewing Angle (Hori/Vert), typical – 178° / 178°
  • Contrast Ratio – 1000:1 (static); 20,000,000:1 (dynamic)
  • Backlight (typical) – LED; 40,000 hour brightness half-life
  • Tempered Glass Window (non-touch screen) – chemically tempered glass; AR coated
  • Optional Acrylic Window (non-touch screen) – acrylic glazing provides a scratch-resistant and shatter-resistant window; anti-reflective coating with 99% reduction of glare; thermal insulating and anti-static; 99% UV blocking

Video

  • Input Connectors – HD-15, DVI-D
  • Compatible Inputs Using Optional Adapter (call for details)
    • HDMI (via HDMI to DVI adapter)
    • DisplayPort (via DisplayPort to DVI adapter)
    • BNC (via HD-15 to 5-wire BNC adapter)
  • Input Signal Formats
    • RGB Analogue video, 0.7/1.0 Vp-p, 75 Ohms; Compatible sync modes: Separate H/V sync, Composite sync, Sync on Green
    • DVI
    • NTSC/PAL composite input available; call for details
  • Horizontal Scan – 24-82 kHz
  • Vertical Scan – 50-75 Hz
  • Supported Video Standards – SXGA – 1280 x 1024 @ 60 (native), 75 Hz; 1280 x 960 @ 60, 75 Hz; 1024 x 768 @ 60, 70, 75 Hz; 800 x 600 @ 56, 60, 72, 75 Hz; 720 x 400 @ 70 Hz; 640 x 480 @ 60, 75 Hz; see user manual for a full list of resolution and timing compatibility
  • Response Rate (typical) – 14 ms

Electrical

  • Power Input
    • AC Power Models – 100 to 240 VAC, 1.5/0.75 A, 60/50 Hz
    • DC Power Models – 9.6 to 36.6 VDC, 2.5 to 0.65 A, Class 2 or SELV/LPS
  • Power Consumption (typical) – 16 W
  • Power Consumption (standby mode) – < 0.5 W

Environmental

  • Panel Rating (with proper installation)
    • Black Powder-Coated Carbon Steel Models – built to IP65/IP66 standards; NEMA/UL Type 12/4
    • Stainless Steel Models – built to IP65/IP66 standards; NEMA/UL Type 12/4/4X
    • More on IP / NEMA ratings
  • Operating Temperature – 0° to 50°C
  • Storage Temperature – -20° to 60°C
  • Humidity – 20% to 90% non-condensing
  • Operating Shock – 15 g, 6 msec, half-sine
  • Operating Vibration (sine) – 1.0 g, swept sine 9-500 Hz
  • Transport Vibration (random) – 0.1g² / Hz, 10-200 Hz; 0.03g² / Hz, 200-2000 Hz
  • Altitude – Operating: up to 3.05 km; Non-operating: up to 12.19 km
  • Environmental Sulphur Gas Protection Option – includes glass-armoured touch screen, vapour-phase corrosion inhibitor, and extensive sealing; call for details. More on Sulphur Gas Protection.

Functional

  • Panel Controls (rear access) – 1 (Menu), 2 (Enter), Down, Up, Power
  • OSD (On Screen Display) Controls – Auto Image Adjust, Contrast / Brightness, Input Select, Color Adjust, Information, Manual Image Adjust, Setup, Memory Recall

Physical

  • Enclosure Type – panel mount; rear collar compresses gasket against panel; held by 12 M5 studs
  • Maximum Panel Thickness – 7.9 mm
  • Bezel Material – black powder-coated carbon steel or stainless steel faceplate
  • VESA Mount Holes – available using adapter, see Accessory Mounting Bracket Option below
  • Maximum Depth Behind Panel – 53.8 mm
  • Front Bezel Outside Dimensions (W x H x D) – 482.6 mm x 398.8 mm x 7.1 mm (not including gasket)
  • Cutout Dimensions (W x H) – 453.4 mm x 366.8 mm; +/- 0.5 mm
  • Net Weight – 8.16 kg
  • Shipping Weight – 9.98 kg

Compliances and Certifications

Touch Screen Option

  • Technology – 5-wire single-touch resistive system with mouse emulation
  • Interface – USB or RS-232 interface to computer (both connections are included on touch screen monitors)

Accessory Mounting Bracket Option

Accessory Mounting Bracket for 19" Panel Mount Monitors, with VESA Mounting Pattern

  • VESA Mounting Pattern – provides 100 mm and 75 mm VESA mounting holes for mounting devices to rear of the display, or for mounting display to a stand; note that the 19″ Panel Mount Display does not have a VESA mounting pattern without using this bracket
  • Custom Mounting Surface – can be drilled to mount other custom devices without drilling into rear of display
  • Attachment to Display – mounts to display via mounting holes on outer edges of bracket
  • Weight Limit – up to 11.3 kg
  • Physical
    • Bracket Dimensions (W x H x D) – 381.0 mm x 127.0 mm x 12.7 mm
    • Panel Space for Mounting Devices (W x H) – 381.0 mm x 127.0 mm
    • Total Display Depth (including bracket) – 67.2 mm
    • Construction – 16-gauge aluminium
19" Industrial Panel Mount Monitors and Touch Screens
Bezel MaterialPower InputWindow OptionPart NumberPrice
Stainless SteelACResistive Touch ScreenHIS-ML19-STAH$880£755€855855 €
Glass (non-touch)HIS-ML19-SGAH$795£690€785785 €
Acrylic (non-touch)HIS-ML19-SAAH$810£705€800800 €
DCResistive Touch ScreenHIS-ML19-STTH$1,015£855€970970 €
Glass (non-touch)HIS-ML19-SGTH$920£785€890890 €
Acrylic (non-touch)HIS-ML19-SATH$940£800€910910 €
Black Powder-Coated Carbon SteelACResistive Touch ScreenHIS-ML19-CTBH$880£755€855855 €
Glass (non-touch)HIS-ML19-CGBH$795£690€785785 €
Acrylic (non-touch)HIS-ML19-CABH$810£705€800800 €
DCResistive Touch ScreenHIS-ML19-CTTH$1,010£855€965965 €
Glass (non-touch)HIS-ML19-CGTH$920£785€890890 €
Acrylic (non-touch)HIS-ML19-CATH$940£800€910910 €
Accessory Mounting Bracket Option
Part NumberPrice
VB-19E$55£80€9090 €
